UTT62
SEPENUHNYA
| Julat Saiz: | |
|---|---|
| Bahan: | |
| Selesai: | |
| MOQ: | |
| Sampel: | |
| Penghantaran: | |
| Kuantiti: | |
Pengapit Paip Biasa UTT62
Julat Saiz： 1/2″ hingga 4″
Bahan： Keluli karbon
Kemasan： Bersalut zink, kemasan lain tersedia atas permintaan
Ciri-ciri：
● Mengandungi mekanisme penutupan yang mudah.
● Tepi menyala dan kawasan kimpalan yang direka khas membantu melindungi paip CPVC.
● Pencuci plastik membantu mengelakkan CPVC atau paip plastik remuk dan memastikan kesesuaian terapung.
| Bahagian Nombor |
Nominal Saiz Paip |
D | M | A | B | H1 | H | Maks.Rec. Muatkan |
||||||||
| dalam. | mm | dalam. | mm | dalam. | mm | dalam. | mm | dalam. | mm | dalam. | mm | dalam. | mm | Ibs | N | |
| CC04-015 | 1/2' | DN15 | 0.85 | 21.5 | 3/8' UNC |
M10 | 2.76 | 70 | 1.18 | 30 | 1.06 | 27 | 1.65 | 42 | 250 | 1110 |
| CC04-020 | 3/4' | DN20 | 1.06 | 27 | 299 | 76 | 1.14 | 29 | 1.85 | 47 | ||||||
| CC04-025 | 1' | DN25 | 132 | 33.5 | 3.27 | 83 | 1.30 | 33 | 2.17 | 55 | ||||||
| CC04-032 | 1/4' | DN32 | 1.67 | 42.3 | 3.62 | 92 | 1.48 | 37.5 | 2.48 | 63 | ||||||
| CC04-040 | 11/2' | DN40 | 1.91 | 48.5 | 3.74 | 95 | 1.61 | 41 | 2.80 | 71 | 320 | 1420 | ||||
| CC04-050 | 2' | DN50 | 2.38 | 60.5 | 4.33 | 110 | 1.85 | 47 | 3.27 | 83 | ||||||
| CC04-065 | 21/2' | DN65 | 2.89 | 73.5 | 4.88 | 124 | 2.11 | 53.5 | 3.74 | 95 | ||||||
| CC04-065A | 21/₂' | DN65 | 3.03 | 77 | 5.00 | 127 | 2.17 | 55 | 3.86 | 98 | ||||||
| CC04-080 | 3' | DN80 | 3.50 | 89 | 5.51 | 140 | 242 | 61.5 | 4.37 | 111 | 380 | 1690 | ||||
| CC04-090 | 31/₂' | DN90 | 4.02 | 102 | 6.10 | 155 | 2.70 | 68.5 | 4.92 | 125 | ||||||
| CC04-100 | 4' | DN100 | 4.53 | 115 | 6.57 | 167 | 2.93 | 74.5 | 5.43 | 138 | 440 | 1950 | ||||
