UTT12D galvanized carbon steel dual-hole seismic hinge with adjustable angle, 14mm hole for M12 bolt, max load 7300N for multi-scenario wall & beam seismic bracing complying with NFPA13 standard.

UTT12C offset galvanized carbon steel seismic hinge with adjustable angle, 14mm hole for M12 bolt, max load 7300N for wall & beam seismic bracing under NFPA13 standards.

UTT12B galvanized carbon steel seismic hinge designed for I-beam mounting, adjustable angle with M12 hole, rated load 7800N for fire sprinkler & MEP pipeline seismic bracing complying with NFPA13.

UTT12A galvanized carbon steel seismic hinge with adjustable angle, M12 mounting hole, max load 7300N for wall lateral & longitudinal seismic bracing per NFPA13.

UTT13 UL & FM certified electro-galvanized carbon steel U-type quick lateral clamp, fits 1''~8'' Sch10/Sch40 sprinkler pipe for NFPA13 compliant seismic sway bracing assembly.

UTT18 UL&CE certified QT450 ductile iron U-type lateral clamp, electro-galvanized finish for 1-1/2''~8'' Sch10/Sch40 sprinkler pipe to build NFPA13 compliant seismic sway bracing assembly.

UTT90 galvanized carbon steel four-way adapter fits pipe up to DN200, max load 6800N for 1" round pipe 90° seismic bracing per NFPA13 requirements.

UTT20Q UL & CE certified pipe clamp made of carbon steel and QT450 ductile iron, electro-galvanized finish for 2''~8'' standard sprinkler pipe, torque 100~115N·M for NFPA13 seismic sway bracing assembly.

UTT8001 electro-galvanized two-piece split pipe clamp mainly matches channel steel, available from 1/2'' to 12'', carbon steel as standard material with optional stainless steel and customizable dimensions for fire and MEP pipeline fixing.

UTT63 electro-galvanized carbon steel suspension clamp is designed for bare hot and cold pipeline without insulation, ranging from 1/2" to 8", max design load 9000N with break-off set screw locking structure for stable pipeline suspension.

UTT1101 electro-galvanized QT450 ductile iron beam adapter clamps steel beam from 3/8'' to 1-1/4'' thickness without drilling or welding, supports bracing for up to 8'' pipe per NFPA13 sway bracing requirements.

UTT1102 electro-galvanized QT450 ductile iron pivoting beam adapter features 1/2" & M12 mounting hole, fits pipeline up to 8", adopts cone point break-off bolt locking and free pivoting design for multi-angle NFPA13 compliant seismic sway bracing installation.
