BC2 Universal Beam Clamp
Function:Structural attachment to top or bottom of metal beams,purlins, channel, or angel iron
Size:3/8"、M10or 1/2"、M12
Material: Ductile iron QT450
Finish:Black or Galvanized
Approval:
The BC2 Universal Beam Clamp is designed for secure structural attachment to the top or bottom of metal beams, including I-beams, purlins, channels, and angle iron. It provides a reliable, non-welded fixing solution for various structural and mechanical support applications.
※Set screw must be tightened and torqued onto the sloped side of the I-beam
| Size | A | B | C | D | E | F | RS | Max.Rec.Load | |
| in | in | in | in | in | in | in | in | Ibs | KN |
| BC1-3/8" | 0.33 | 0.91 | 0.77 | 1.55 | 0.68 | 1.87 | 3/8° | 6.8 | |
| BC1-1/2" | 0.36 | 1.10 | 0.74 | 1.70 | 0.94 | 2.13 | 1/2° | 9 | |
| mm | mm | mm | mm | mm | mm | mm | mm | Ibs | KN |
| BC1-M10 | 8.3 | 23 | 19.5 | 39.3 | 17.3 | 47.5 | M10 | 6.8 | |
| BC1-M12 | 9.2 | 28 | 18.9 | 43.2 | 23.9 | 54.2 | M12 | 9 | |
The BC2 Universal Beam Clamp offers a strong, versatile, and non-invasive solution for structural beam attachment. Manufactured from ductile iron QT450, it delivers reliable load performance and long-term durability. With multiple size options and clear installation guidance, it is well-suited for a wide range of structural and support system applications.
As an experienced universal beam clamp manufacturer and supplier, we offer the BC2 Universal Beam Clamp for sale to globalB2Bcustomers. Our factory supports wholesale beam clamp supply, stable batch production, and consistent quality control, making this product suitable for contractors, distributors, and engineering project procurement.
We provide reliable structural beam clamp solutions for industrial construction, MEP supports, and steel structure systems, with flexible supply capabilities to meet project-based demands.
If you are sourcing a BC2 Universal Beam Clamp supplier or looking for wholesale beam clamps for structural applications, we welcome your inquiry.
Contact us today with your required size, quantity, and project details to receive technical support and a competitive quotation.
Send your inquiry now and let us support your next project with dependable beam clamp solutions.
