UTT62
UTTERLY
| Color: | |
|---|---|
| Material: | |
| Surface: | |
| Quantity: | |
UTT62 plain vertical pipe clamp is specially engineered for vertical pipeline stabilization, focusing on CPVC and plastic piping protection. Constructed from zinc plated carbon steel with customizable alternative surface finishes, the clamp adopts easy-close snap mechanism for fast field assembly; flared curved edges and matched plastic cushion washers effectively prevent pipe wall compression damage and realize floating installation clearance. Full specification range from DN15(1/2")~DN100(4"), equipped with standard M10/UNC mounting screw, different size with graded bearing load, widely applied to vertical CPVC plastic riser, domestic plumbing and fire protection plastic vertical piping projects.
Core Function: Fix and stabilize vertical plastic/CPVC riser pipe, avoid pipeline crushing damage with protective washers
Raw Material: High-strength carbon steel
Surface Finish: Standard zinc plating, customized surface treatment available on request
Core Structure: Easy-close quick closing mechanism + flared protective edge + embedded plastic anti-crush washer
Applicable Pipe: DN15(1/2")~DN100(4") CPVC & plastic vertical pipeline
Mount Bolt: Standard UNC 3/8" / M10 threaded fastener
Rated Load: Graded working load from 1110N up to 1950N by different dimensions
Item | Specification |
|---|---|
Model | UTT62 Series（DN15~DN100 /1/2"~4"） |
Raw Material | Carbon Steel |
Surface Treatment | Zinc plated, other finish customizable |
Applicable Pipe | DN15(1/2")~DN100(4") CPVC/plastic vertical pipe |
Fixing Bolt | UNC 3/8" / M10 standard screw |
Core Protection | Flared edge + built-in plastic anti-crush washer |
Structure | Easy-close snap quick lock design |
Max Rated Load | 1110N ~1950N graded by size |
Sample Supply | Free pre-order test samples available |
1.Fire Protection System: Vertical fixed support for CPVC fire sprinkler riser pipelines in commercial & residential buildings.
2.Plumbing Engineering: Vertical riser fixing for indoor CPVC cold/hot drinking water plastic piping.
3.Industrial Construction: Vertical pipeline stabilization for small-bore plastic process riser inside factory buildings.
1.Select matched UTT62 size per outer diameter of target CPVC/plastic vertical pipe.
2.Open the easy-close clamp and snap onto pipeline with built-in plastic washer closely fitting pipe outer wall.
3.Make full use of flared edge to avoid sharp metal contact scratching pipe surface.
4.Fasten M10/UNC bolt to lock the clamp body tightly and form floating installation gap via plastic cushion.
5.Fix the top mounting hole onto building structural floor/beam to finish vertical riser supporting installation.
1.Conforms to international CPVC pipeline installation specifications and domestic plumbing construction standards.
2.Zinc plating surface meets regular anti-rust coating industrial norms; plastic washers comply with pipeline contact environmental requirements.
3.All finished products pass factory dimension inspection and load bearing sampling test before delivery.
Flared smooth edge + embedded plastic double protection prevents plastic pipe crushing and scratch during clamping.
One-step closing design greatly shortens vertical pipe on-site assembly time and improves construction efficiency.
Standard zinc plating for regular indoor use, alternative coating available for special damp/corrosive environment.
Elastic plastic washer leaves reserved gap to adapt pipeline thermal expansion and contraction of CPVC material.
Different size with corresponding rated load to satisfy varied vertical plastic pipeline dead weight requirements.
Perfectly matched with UTT threaded rod, beam adapters and other pipe clamps for complete vertical support system.
Q1: What is UTT62 exclusive design for plastic pipe?
A1: Flared edge plus built-in plastic anti-crush washer to prevent CPVC pipe compression damage and achieve floating installation.
Q2: Available surface options?
A2: Standard zinc plating finish, other customized surface treatments available upon customer request.
Q3: Matching mounting fastener?
A3: Fits UNC 3/8 inch or M10 standard bolt for structure fixing.
Q4: Applicable pipe specification?
A4: Covers DN15(1/2") up to DN100(4") CPVC and plastic vertical riser pipe.
Q5: Free sample support?
A5: Free inspection samples can be supplied before bulk order confirmation.
