UTT8003
UTTERLY
| Material: | |
|---|---|
| Finish: | |
| Size: | |
| Sample: | |
| MOQ: | |
| Delivery: | |
| Quantity: | |
The Insulation Pipe Clamp is engineered to do more than simply hold pipes in place—it protects, stabilizes, and extends the lifespan of your entire piping system. Designed with an integrated insulation layer, it creates a soft yet firm grip around the pipe, reducing vibration, preventing wear, and maintaining thermal efficiency.
When installed, the cushioned lining gently embraces the pipe surface, eliminating harsh metal-to-metal contact. In operation, you won’t hear rattling or feel unwanted movement—just a quiet, controlled system working exactly as intended.
Whether used in HVAC systems, industrial pipelines, or building infrastructure, this clamp transforms a simple fixing point into a long-term protection solution. It is not just a component—it is a safeguard for performance, safety, and durability.
Primarily used for securing vibrating pipes with pipe clamps. The pipe is fully wrapped in a flexible rubber seat, effectively eliminating rigid contact points and minimizing vibration. Suitable for use in high and low-pressure piping systems, fire protection systems, refrigeration and HVAC systems, as well as electrical wiring and cable installations.
1. Provides excellent vibration dampening, noise reduction, and insulation.
2. Easy to install and ideal for space-saving, cost-efficient layouts by allowing tight pipe-to-pipe installation.
3. Utilizes channel steel structure for improved load-bearing performance.
4. Equally effective for vertical pipe installations.
| Model | OD(m) | Thickness | Carriage Bolt | W/100 |
| UTT8003 | 19.1-21.7 | 1.5m | Mox25 | 7 |
| 25.0-27.2 | 1.5m | Mox25 | 8 | |
| 31.8-34.0 | 2.0nn | Mbx25 | 9 | |
| 38.1-42.7 | 2.0nn | M6x25 | 9 | |
| 48.6-50.8 | 2.6m | MB×40 | 18 | |
| 60.5-63.5 | 2.5nn | M8×40 | 21 | |
| 75.0-76.3 | 2.5mn | M8×40 | 24 | |
| 89.1-90.0 | 2.5m | M8×40 | 27 | |
| 108.0-114.3 | 3.0nn | H10×40 | 40 | |
| 125.0-139.8 | 3.0nn | M10×40 | 47 | |
| 159.0-165.2 | 3.5m | W10×40 | 58 | |
| 200.0-216.3 | 3.5m | M10×40 | 76 |
Material:
High-quality carbon steel / Stainless steel
Surface Treatment:
Electro-galvanized (zinc plating), Hot-dip galvanized
Galvanization Standard:
Minimum zinc coating thickness of 7μm for electro-galvanized finish;
Minimum zinc coating thickness of 45μm for hot-dip galvanized finish
Insulated Anti-Vibration Pad:
Made from UV-resistant thermoplastic elastomer.
Material of the Insulated Pad:
Hard rubber.
Temperature Rating:
45°C to +135°C
Product Includes:
Clamp + Insulated Anti-Vibration Pad + Carriage Bolt and Nut
In many piping systems, constant vibration leads to noise, wear, and eventual failure. This insulation pipe clamp absorbs and dampens those vibrations at the source. The cushioned inner layer acts like a buffer, reducing operational noise and creating a quieter, more stable environment—especially important in commercial buildings and sensitive installations.
Direct contact between metal clamps and pipes can cause scratches, corrosion, and long-term damage. This clamp eliminates that risk. The insulation layer prevents abrasion and protects the pipe surface, extending its service life and reducing maintenance costs over time.
Temperature loss and condensation are common challenges in piping systems. By integrating insulation directly into the clamp, it helps maintain consistent temperature conditions and reduces energy waste. This makes it especially valuable in HVAC and refrigeration systems where efficiency matters.
Designed for practicality, the clamp offers a firm and secure fit while remaining easy to install. Its structure allows quick mounting without complicated adjustments, saving time during installation and ensuring consistent results across projects.
| Feature | Insulation Pipe Clamp | Standard Pipe Clamp |
| Pipe Protection | Cushioned lining prevents damage | Direct metal contact |
| Noise Reduction | Excellent vibration damping | Minimal noise control |
| Thermal Efficiency | Maintains insulation | No insulation support |
| Durability | Longer pipe lifespan | Higher wear risk |
The integrated insulation layer reduces vibration, protects the pipe surface, and improves thermal efficiency, making it a more advanced solution.
Yes, with corrosion-resistant coating, it performs well in outdoor and humid environments.
Yes, we support different materials, sizes, and surface treatments based on your requirements.
